Epoch 12V 460Ah V2 | LiFePO4 Battery
Epoch 12V 460Ah V2 | LiFePO4 Battery
- IP 67 Waterproof
- iOS, Android Apps
- 3500+ Cycles
- Advanced BMS
- Internal Heating
- Safe & Reliable
Improved Victron Communications: High Voltage Alarm Fix: This addresses issues where high voltage alarms were triggered incorrectly in the V1 model. Improved communication should result in better monitoring and control of the battery system.
Improved Scalability: Parallel Capability: The system can now handle up to 16 batteries in parallel, compared to the previous limitation of just 4. This greatly expands the potential for energy storage, allowing for larger systems.
Upgraded Internal Components: Certified Components: The internal fuse is UL60691 certified, and the battery cells meet a range of safety and quality standards, including UL1642, UL1973, U9540A, IEC 62619:2017, and RoHS. This indicates that the battery is built to high safety standards and is suitable for various applications.
Battery UL Listing: The battery is in the process of receiving its UL Listing (a certification for safety and quality). This will further confirm its compliance with industry standards.
Improved Bluetooth App Compatibility: All-Battery Dashboard: The app now supports connecting to and monitoring all batteries from a single dashboard, even if you have up to 16 batteries in your system. This makes it easier to manage large-scale installations.
BMS Over-the-Air Firmware Updates: The system can now receive firmware updates remotely via the app. This ensures the battery management system (BMS) is always running the latest software, which can improve performance, security, and features over time.
Upgraded Battery Gauge: Better Monitoring: The new battery gauge provides more detailed information, including State of Charge (SOC), voltage, current flow, and alarm alerts. This is a significant improvement over the older version, which only had a 10-segment gauge. The added details help with better monitoring of the system's health and performance.
* Due to the specialized nature of batteries, shipping rates vary based on destination and courier requirements. To ensure the best shipping experience, we collaborate with reputable freight couriers to determine accurate rates once you’ve contacted us with your order and provided your address.
Features
Specifications
Product Support
- LiFePO4 Chemistry
- Group 8D Size (20.9" x 8.7" x 12.1") L x W x H
- 460Ah Capacity
- 300A Max Continuous Discharge (500A 30s Discharge)
- 230A Max Continuous Charge (300A 10s Charge)
- IP67 Rated, Dust and WATERPROOF
- HEATED - Internal heating for below 0C charging
- BLUETOOTH - iOS and Android Apps
- CANBUS Communication allows BMS to communicate directly with Victron OS
- Mountable ON/OFF Switch
- Mountable Battery gauge
- Built-in Smart Battery Management System (BMS)
- Internal fuse with current and temperature protections
- Over charge and over discharge protection
- Over current and short circuit protection
- High & low temperature disconnects
- 3500+ Cycle life & Maintenance-free
- 11 Year Manufacturer Warranty
WEIGHT
97 lbs
DIMENSIONS
- Length: 20.75"
- Width: 8.5"
- Height: 12"
CONFIGURATION
- Cell Configuration: 4S2P
- Chemistry: LiFePO4
CURRENT
- Ah Capacity: 460Ah
- Max Continuous Discharge Amps: 300A
- Max Charge Current Amps: 230A
- Max Discharge Peak Current Amps: 500A (30 Seconds) , 1300A (1 Second)
- Series | Parallel: Max (4) in Series OR Max (4) in Parallel - 4S1P or 1S4P
VOLTAGE
- Voltage: 12.8V
- Max Charge Voltage: 14.6V
- Operating Voltage Range: 10.0 - 14.6V
TEMPERATURE
- Charge Temp Range: -20°C (-4°F) / 55°C (131°F) (with heating)
- Discharge Temp Range: -20°C (-4°F) / 60°C (140°F)
- Storage Temp: 0°C (32°F) / 35°C (95°F)
